PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG

    Buy cheap PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG from wholesalers

    Buy cheap PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG from wholesalers
    • Buy cheap PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG from wholesalers
    • Buy cheap PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG from wholesalers

    PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG

    Ask Lasest Price
    Brand Name : JASU
    Model Number : ISB 800AN-3
    Certification : CE, BV, ISO9001, SGS, UKAS, LAF
    Price : USD40000-120000 per unit
    Payment Terms : T/T
    Supply Ability : 500 sets per month
    Delivery Time : 34-50 Days
    • Product Details
    • Company Profile

    PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG

    Automatic PET Blowing Machine, PET Bottle Machine Price, Stretch Blow Molding Machine for TRITAN
    One Step Injection Stretch Blow Molding Machine (ISBM machine) is the Best Solution for Hollow Blow Molding Products

    Injection Stretch Blow Moulding is the process of manufacturing high quality and very high clarity bottles.
    The plastic is melted and then injected into a mold to form a preform.
    When the preform is in the mold it is then inflated using high pressured air while simultaneously being stretched.
    While the plastic is inside the mold, the plastic will freeze off to the mold shape as it is forced against the inside of the mold.
    The mold halves will then open releasing the bottle so that the process can be repeated.


    Advantages of Injection Stretch Blow Molding Machine

    • Small capital investment in equipment
    • High speed and efficient, energy saving and stable, easy for operation and maintanance
    • Low production time required
    • No need to deflashing and trimming
    • Flexibility in production: Injection Molded neck finish allow for bottle orientation
    • Highly customizable process, making it easily adaptable to different scales
    • Can manufactured for more complex shape

    Data Sheet of JASU Injection Stretch Blow Molding Machine (ISBM)


    ItemUnitMachine Type
    ISB 800AN-3
    Injection PartScrew Diametermm50
    Screw L/D RatioL/D20.5:1
    Screw Speedr/min0-150
    Theoretical Injection Capacitycm3481
    Injection PressureMPa176
    Max. Hydraulic PressureKg/cm140
    The Actual Injection Quantityg(ps)452
    Oz16
    Screw Strokemm245
    Clamping PartBlow Clamping ForceKN80
    Clamp TonnageKN400
    Wheel Diametermm800
    Max. HeightPP, PET, PETG, Tritan, PS, PCmm200
    PC, PETG, Tritan, PSmm220
    Open Vertical Mode Tripmm570
    OthersMax. Pump PressureMPa16
    Servo MotorKw22
    Mode Opening/Locking Motor (Double Pump)Kw22
    Electric PowerKw12.2
    Tank VolumeL420
    Dimension of Machinem4.2*1.75*3.4
    Machine WeightT6
    --Parameters are subject to change without prior notice.
    --Providing PC, PET, PP, PS, PETG, TRITAN screw barrels according to customers' requirements.


    PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG


    One step injection stretch blow molding machine is widely used for various plastic materials and has broad application prospects.


    The machine can mold different types of containers, such ascosmetics, pharmaceuticals, infusion bottles, detergent, mouth wash, baby feeding bottles, spice, salad dressing, food, liquor, PET Can, industrial containers etc.


    Regardless of the category, there are many unique applications for stretch blow molding. As mentioned, one application is the manufacturing of bottles used for beverages. However, manufacturers use this same process to make bottles that hold household cleaners, plastic food containers, health and oral hygiene products, agricultural containers, bathroom and toiletry products, and much more. With such a broad reach, it is easy to see why this method of blow molding is in such high demand.


    A large range of refined and essential designed platic blow molded bottles and jars are available from size 10ml to 2500ml.


    PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG


    JASU is the first PET Bottle Machine Manufacturers of Single Stage PET Blowing Machine


    Absorbed the advanced technology from Japan and Germany.
    Manufacturer/Direct Factory with production base takes 24000m2.
    Own highly qualified technical staffs (20-30 persons) and R/D center.
    Obtained a number of technical patents.
    Overseas sales increase 33% annually.

    Market network throughout the country , and export to many countries of East Europe, South America, South Africa etc.
    Our machine enjoyed high reputation among customers.

    Service technicians (holding visa and passport) are on call and able to serve on site and instruct via voice and videos.

    Mould and tooling, we have our own mold-making facility and mould workshop ourselves, advanced CNC machine and smart design engineers.

    We can treat different materials and sizes of products.

    Auxiliary machine,we will equip you with the necessary quality auxiliary machines to ensure the production plan running well.

    Provide one-stop service.


    PET Bottle Preform Full Automatic Blow Molding Machine 30ml 40ml PETG


    Question & Answer

    Q1: Are you a factory or trading company?
    A1: We are established in 2003, a actual factory and manufacturer in the line of injection blow molding machine for 18 years.
    Q2: Where is your factory located? How can I visit you?
    A2: Our factory is located in Panyu District, Guangzhou, Guangdong Province, China, about 48 minutes by high-speed railway from Hong Kong.
    5 minutes driving away from Shiqiao subway station.
    We can book hotel for you and pick you up from CAN BAIYUN airport or Guangzhou south railway station.
    Q3: How about the payment term?
    A3: Advancement (subject to our marketing strategy and both parties' discussion) and settle the balance payment prior to delivery.
    Q4: What about your main market?
    A4: Our machines were sold well in China, also exported and enjoyed a good reputation among customers from Europe, Russia, Southeast Asia, Middle and South America, Africa etc.
    Our customers widely spread over Russia, Italy, Poland, Turkey, Netherlands, Sweden, Bulgaria, Brazil, Ecuador, Thailand, India, Myanmar, Malaysia, Vietnam, Cambodia, Egypt, Algeria, South Africa, Ivory Coast, Philippines, Bangladesh......
    Q5: How does your factory do regarding quality?
    A5: Quality is the most important principle. JASU people always attach great importance to quality controlling from the very beginning to the very end. Our factory has passed ISO and CE certification. Patents and many other certificates obtained also tells this.
    Q6: What about warranty and do the engineers available to overseas?
    A6: One year warranty. During this period, if you need any support on installation, adjustment , operation or maintenance, our engineers can go abroad to fix for you.
    Q7: Others?
    A7: We will request the working voltage and power frequency at the buyer's side upon placing the order.

    1. Each order will be fulfilled as a turn key project of machine.
    2. We will check and test the machine and send the video to the customer for reference prior the delivery.
    3. Attache/send an operational manual in English version with the shipment.
    4. To use the machine only need to connect power and connect to the air supply and water supply according to the manual or video instructions if requested.
    5. Service technicians are on call to instruct via voice and videos. They all hold visa and passport and be able to serve on site.
